weidmuller 9537470000 Brown WDU Feed Through Terminal Block, Single level, 6mm², 500 V
weidmuller 9537470000 Brown WDU Feed Through Terminal Block, Single level, 6mm², 500 V Product Description Spring Loaded Extra security version of the W series terminals with a spring under the cable clampProvides a secure contact even if the terminal is not correctly tightenedFor use with a hook blade crimpFor use...
weidmuller 9537470000 Brown WDU Feed Through Terminal Block, Single level, 6mm², 500 V
Product Description
Spring Loaded
Extra security version of the W series terminals with a spring under the cable clamp
Provides a secure contact even if the terminal is not correctly tightened
For use with a hook blade crimp
For use on either a TS32 or TS35 rail
Flammability rating UL94V-0
Voltage rating 500 V
Note
The spring loaded terminals can be used on TS32 AND TS35 rail.
Approvals
(Additional) ATEX KEMA 98 ATEX 1683U
Approvals
1-11
The ’W’ series screw clamp terminals are suitable for ’Top Hat’ DIN Rail and manufactured from nylon 6.6 which has a continuous temperature rating of 120°C (180°C short term). They are self-extinguishing to UL94V-0 and free from cadmium and halogen. Current bars are constructed from 10 mm electrolytic copper to ensure a current loading more than nominal rating. Terminals are suitable for mounting on symmetric ’Top Hat’ rail only (BS5584:1978, EN 50022) and are touch proof in accordance with BS 3042.
Specifications
Product Description
Extra security version of the W series terminals with a spring under the cable clamp
Provides a secure contact even if the terminal is not correctly tightened
For use with a hook blade crimp
For use on either a TS32 or TS35 rail
Flammability rating UL94V-0
Voltage rating 500 V
Provides a secure contact even if the terminal is not correctly tightened
For use with a hook blade crimp
For use on either a TS32 or TS35 rail
Flammability rating UL94V-0
Voltage rating 500 V
The spring loaded terminals can be used on TS32 AND TS35 rail.
(Additional) ATEX KEMA 98 ATEX 1683U
1-11
The ’W’ series screw clamp terminals are suitable for ’Top Hat’ DIN Rail and manufactured from nylon 6.6 which has a continuous temperature rating of 120°C (180°C short term). They are self-extinguishing to UL94V-0 and free from cadmium and halogen. Current bars are constructed from 10 mm electrolytic copper to ensure a current loading more than nominal rating. Terminals are suitable for mounting on symmetric ’Top Hat’ rail only (BS5584:1978, EN 50022) and are touch proof in accordance with BS 3042.
Specifications
| Attribute | Value |
| Colour | Brown |
| Number of Levels | Single |
| American Wire Gauge | 20 ? 8AWG |
| Series | WDU |
| Termination Method | Screw |
| Cable CSA | 6mm² |
| Current Rating | 57A |
| Voltage Rating | 500 V |
