weidmuller 1020010000 Black WDU Feed Through Terminal Block, Single level, 2.5mm², ATEX, 800 V
weidmuller 1020010000 Black WDU Feed Through Terminal Block, Single level, 2.5mm², ATEX, 800 V Product Description ’W’ Series Terminal Blocks One key advantage of the W-Series is the choice of plug-in (ZQV) or screw-in (WQV) cross-connections within one modular terminal. Saving substantial time in comparison to other screw terminals. Features...
weidmuller 1020010000 Black WDU Feed Through Terminal Block, Single level, 2.5mm², ATEX, 800 V
Product Description
’W’ Series Terminal Blocks
One key advantage of the W-Series is the choice of plug-in (ZQV) or screw-in (WQV) cross-connections within one modular terminal. Saving substantial time in comparison to other screw terminals.
Features and Benefits:
Terminals available in a range of colours
Screw-in and a plug-in cross connection system is available for screw terminals
Product Application Information
Handy components to build up your terminal block, with simple time saving options. Thanks to the unique design patent, you can now connect two conductors of the same cross section into the same clamping point without difficulty.
A great solution if you want to connect your assembly together without getting shocked or the possibility of something becoming loose. Simply attach to your terminal block, screw down, and securely clamp in place.
Approvals
CSA certified, UL listed, SEV, DEMKO, NEMKO, LLOYDS REGISTER OF SHIPPING, SETI, KEMA, Reg of USSR
Weidmuller Feed-Through Terminal Block, 800V Voltage Rating, 30 to 12AWG Wire Size - WDU Series - 1020010000
Need a reliable way to connect two wires? This single-level feed-through terminal block from Weidmuller will do the job. It's designed with screw terminals made from steel and tinned copper for dependable conductivity and a secure connection. As this unit accepts solid, stranded and ferrule-ended wires in sizes between 30 and 12AWG, you can tick versatility off your wish list. The block's Wemid housing is resistant to impact and wear, making it a long-lasting choice in tough environments.
Features & Benefits
• Wide operating temperature range between -50°C and +120°C for use in harsh conditions
• Rear clips mean you'll have it attached to your DIN rail in no time
• Self-extinguishing for safety in the event of a fire
• Compact dimensions of 60 (H) x 5.1 (W) x 46.5mm (D) to maximise packing space on your rail
Applications
• Power distribution
• Safety systems
• Process control
• Machine automation
Can I use this feed-through terminal block in high-power circuits?
Thanks to its voltage rating of 800V, this terminal block has no trouble handling high-power applications.
Approvals
1-10
The ’W’ series screw clamp terminals are suitable for ’Top Hat’ DIN Rail and manufactured from nylon 6.6 which has a continuous temperature rating of 120°C (180°C short term). They are self-extinguishing to UL94V-0 and free from cadmium and halogen. Current bars are constructed from 10 mm electrolytic copper to ensure a current loading more than nominal rating. Terminals are suitable for mounting on symmetric ’Top Hat’ rail only (BS5584:1978, EN 50022) and are touch proof in accordance with BS 3042.
Specifications
Product Description
One key advantage of the W-Series is the choice of plug-in (ZQV) or screw-in (WQV) cross-connections within one modular terminal. Saving substantial time in comparison to other screw terminals.
Terminals available in a range of colours
Screw-in and a plug-in cross connection system is available for screw terminals
Screw-in and a plug-in cross connection system is available for screw terminals
Handy components to build up your terminal block, with simple time saving options. Thanks to the unique design patent, you can now connect two conductors of the same cross section into the same clamping point without difficulty.
A great solution if you want to connect your assembly together without getting shocked or the possibility of something becoming loose. Simply attach to your terminal block, screw down, and securely clamp in place.
CSA certified, UL listed, SEV, DEMKO, NEMKO, LLOYDS REGISTER OF SHIPPING, SETI, KEMA, Reg of USSR
Need a reliable way to connect two wires? This single-level feed-through terminal block from Weidmuller will do the job. It's designed with screw terminals made from steel and tinned copper for dependable conductivity and a secure connection. As this unit accepts solid, stranded and ferrule-ended wires in sizes between 30 and 12AWG, you can tick versatility off your wish list. The block's Wemid housing is resistant to impact and wear, making it a long-lasting choice in tough environments.
• Wide operating temperature range between -50°C and +120°C for use in harsh conditions
• Rear clips mean you'll have it attached to your DIN rail in no time
• Self-extinguishing for safety in the event of a fire
• Compact dimensions of 60 (H) x 5.1 (W) x 46.5mm (D) to maximise packing space on your rail
• Rear clips mean you'll have it attached to your DIN rail in no time
• Self-extinguishing for safety in the event of a fire
• Compact dimensions of 60 (H) x 5.1 (W) x 46.5mm (D) to maximise packing space on your rail
• Power distribution
• Safety systems
• Process control
• Machine automation
• Safety systems
• Process control
• Machine automation
Thanks to its voltage rating of 800V, this terminal block has no trouble handling high-power applications.
1-10
The ’W’ series screw clamp terminals are suitable for ’Top Hat’ DIN Rail and manufactured from nylon 6.6 which has a continuous temperature rating of 120°C (180°C short term). They are self-extinguishing to UL94V-0 and free from cadmium and halogen. Current bars are constructed from 10 mm electrolytic copper to ensure a current loading more than nominal rating. Terminals are suitable for mounting on symmetric ’Top Hat’ rail only (BS5584:1978, EN 50022) and are touch proof in accordance with BS 3042.
Specifications
| Attribute | Value |
| Colour | Black |
| Number of Levels | Single |
| Series | WDU |
| American Wire Gauge | 30 ? 12AWG |
| Termination Method | Screw |
| Cable CSA | 2.5mm² |
| Current Rating | 32A |
| Voltage Rating | 800 V |
| Minimum Operating Temperature | -50°C |
| Maximum Operating Temperature | +120°C |
| Hazardous Area Certification | ATEX |
| Standards Met | CSA |
