weidmuller 1813390000 BU/SU 10.16HP 8-pin PCB Connector, 10.16mm Pitch
weidmuller 1813390000 BU/SU 10.16HP 8-pin PCB Connector, 10.16mm Pitch Product Description The Weidmuller PCB Connector has Single-row, high-current male header, for side-beside mounting without sacrificing any poles, or with patented flange for fast locking without tools. Maximum connection and operating reliability thanks to a mating profile that prevents incorrect connection,...
weidmuller 1813390000 BU/SU 10.16HP 8-pin PCB Connector, 10.16mm Pitch
Product Description
The Weidmuller PCB Connector has Single-row, high-current male header, for side-beside mounting without sacrificing any poles, or with patented flange for fast locking without tools. Maximum connection and operating reliability thanks to a mating profile that prevents incorrect connection, with unique coding diversity and additional fastening in the flange. 3.5mm pin length is optimised for wave soldering, plug-in direction 90° to solder pins.
Mounting onto the PCB THT solder connection
Pitch in mm (P) 10.16 mm
Outgoing elbow 90°
Number of poles 2
Number of solder pins per pole 3
Specifications
Product Description
The Weidmuller PCB Connector has Single-row, high-current male header, for side-beside mounting without sacrificing any poles, or with patented flange for fast locking without tools. Maximum connection and operating reliability thanks to a mating profile that prevents incorrect connection, with unique coding diversity and additional fastening in the flange. 3.5mm pin length is optimised for wave soldering, plug-in direction 90° to solder pins.
Mounting onto the PCB THT solder connection
Pitch in mm (P) 10.16 mm
Outgoing elbow 90°
Number of poles 2
Number of solder pins per pole 3
Pitch in mm (P) 10.16 mm
Outgoing elbow 90°
Number of poles 2
Number of solder pins per pole 3
Specifications
| Attribute | Value |
| Number of Contacts | 8 |
| Pitch | 10.16mm |
| Number of Rows | 1 |
| Mounting Type | PCB |
| Gender | Male |
| Series | BU/SU 10.16HP |
