weidmuller BCF 3.81/05/180F SN BK BX - 1971620000 BC 3.81 5-pin Pluggable Terminal Block, 3.81mm Pitch, Screw Termination
weidmuller BCF 3.81/05/180F SN BK BX - 1971620000 BC 3.81 5-pin Pluggable Terminal Block, 3.81mm Pitch, Screw Termination Product Description BCF Flanged Socket Connectors - 180° Push In These Weidmuller BCF series of Flanged 180° plug socket connectors have a simple Push In system for conductor connection with an integrated...
weidmuller BCF 3.81/05/180F SN BK BX - 1971620000 BC 3.81 5-pin Pluggable Terminal Block, 3.81mm Pitch, Screw Termination
Product Description
BCF Flanged Socket Connectors - 180° Push In
These Weidmuller BCF series of Flanged 180° plug socket connectors have a simple Push In system for conductor connection with an integrated push-button for opening the terminal point. The cable range for these BCF socket connectors is 0.14 - 1.5 mm² (24-16 AWG).
Note
For mating 3.81 mm pitch SC flanged Headers see stock number for 180° and for 90° typical.
3.81mm Pitch - Weidmuller Omnimate Range
Specifications
Product Description
These Weidmuller BCF series of Flanged 180° plug socket connectors have a simple Push In system for conductor connection with an integrated push-button for opening the terminal point. The cable range for these BCF socket connectors is 0.14 - 1.5 mm² (24-16 AWG).
For mating 3.81 mm pitch SC flanged Headers see stock number for 180° and for 90° typical.
3.81mm Pitch - Weidmuller Omnimate Range
Specifications
| Attribute | Value |
| Number of Contacts | 5 |
| Pitch | 3.81mm |
| Number of Rows | 1 |
| Mounting Type | Through Hole |
| Gender | Female |
| Termination Method | Screw |
| Type | Plug |
| Current Rating | 17.5A |
| Body Orientation | Straight |
| Colour | Black |
| Voltage Rating | 320 V |
| Series | BC 3.81 |
| Length | 29.44mm |
| Material | Nylon |
| Width | 7.9mm |
| Depth | 22mm |
