Fluke T110 2-Pole Voltage and Continuity Electrical Tester with Switchable Load, AC/DC 12V to 690V

Powerpro company Limited is the distributor, supplier and service provider of ( Test Equipment Product Sales, Test Equipment Calibration, Test Equipment Rentals and Product Training) in Nigeria.

The Fluke T110 2-Pole Voltage and Continuity Electrical Tester with Switchable Load, AC/DC 12V to 690V gives users fast answers and let them work in a safer way. Thanks to this electrical tester, users can check the presence of voltage before working on any circuit. A clear audible and vibrating voltage indicator lets users work with confidence. The Fluke T110 rugged and reliable electrical tester also features an electric flashlight, a backlit LED indicator to get test results the way you want them.

The T110 two-pole voltage and continuity tester measures voltage, but just as important is alerting users that there is NO voltage present before working on any circuit. Cable assemblies are often where failures occur. The cable on any two-pole voltage and continuity tester is its weakest point - it is repeatedly bent, twisted, wrapped and put under constant strain. If the cable were to break, it could place the user at an increased safety risk. Industry standards call for the cable to be tested to withstand a forty-five-degree bend, and still work after 5000 bend cycles. Fluke puts its testers through three times what the standard demands, flexing the cable over 150 degrees in each direction.

Product Features:

• Dual insulated cable tested to 3x the required bend angle provides increased reliability and durability
• Switchable load to avoid display of ghost voltages, allowing users to draw more current from circuit under test and avoid trip residual-current devices (RCDs)
• Backlit graduated scale and backlit indicators
• Built in electric flashlight for use in dark areas
• Audio on/off for continuity testing in quiet areas
• Improved probe docking for secure storage
• Phase rotation indicator for 3-phase systems
• Single-pole phase test offers fast identification of live conductors
• Push-on probe tips, probe tip protector and storage accessory
• Low battery indicator
• Continuity test with visual results
• Vibratory indicator under load
• Voltage test
• Indication of polarity
• Rotary field indicator
• Voltage detection with discharged batteries
• Wear indicator test lead wire
• Voltage AC/DC: 12V to 690V
• Continuity: 0 to 400 k?
• Frequency: 0 / 40 to 400 Hz
• Phase rotation: 100 V to 690 V
• Response time (LED indicator): < 0.5 s
• 200 k? input impedance: Current draw 3,5 mA @ 690 V / Current draw 1,15 mA @ 230 V
• 7k ? input impedance (with load buttons pressed): Current draw 30 mA @ 230 V
• Safety rating: CAT III 690V / CAT IV 600V
• IP rating: IP64
• Power requirement: 2-AAA batteries
• Warranty: 2 years
