Fluke Fluke 279 FC Handheld Digital Multimeter, True RMS, 2.5kA ac Max, 1000V ac Max
Product DetailsThe 279 FC is a full-featured digital multimeter with integrated thermal imaging and is designed to increase your productivity and confidence. With the second battery in the Fluke 279 FC I/B, you'll always have battery power Fluke 279 FC True-rms Thermal Multimeter helps you find, repair, validate, and report...
Product Details
The 279 FC is a full-featured digital multimeter with integrated thermal imaging and is designed to increase your productivity and confidence. With the second battery in the Fluke 279 FC I/B, you'll always have battery power Fluke 279 FC True-rms Thermal Multimeter helps you find, repair, validate, and report many electrical issues quickly so that you are confident problems are solved. Plus, the 279 FC I/B ships with a second rechargeable battery, so you can always have one in the meter, and one in the charger.
Full-featured multimeter with built-in thermal imager
15 measurement functions
Low-pass filter for troubleshooting adjustable speed drives
Thermal imaging reveals hots spots that may indicate electrical issues quickly and safely
102x77 image resolution
3.5 in /8.89 cm color LCD screen
Rechargeable lithium ion
Auto power off to save battery power
Designed for durability, built to withstand a 3 m (9.8 ft) drop, double insulated with raised rubber holster for increased protection
15 measurement functions
Low-pass filter for troubleshooting adjustable speed drives
Thermal imaging reveals hots spots that may indicate electrical issues quickly and safely
102x77 image resolution
3.5 in /8.89 cm color LCD screen
Rechargeable lithium ion
Auto power off to save battery power
Designed for durability, built to withstand a 3 m (9.8 ft) drop, double insulated with raised rubber holster for increased protection
Specifications
| Attribute | Value |
| Multimeter Type | Handheld |
| True RMS | Yes |
| Functions Measured | AC Current, AC Voltage, Continuity, DC Current, DC Voltage, Diode Test, Frequency, Resistance |
| Absolute Maximum DC Voltage Measurement | 1000V dc |
| Absolute Maximum AC Voltage Measurement | 1000V ac |
| Absolute Maximum Resistance Measurement | 50M? |
| Absolute Maximum AC Current Measurement | 2.5kA ac |
| Absolute Maximum Temperature Measurement | 200 °C, 392°F |
| Absolute Maximum Capacitance Measurement | 9.999mF |
| Maximum Frequency | 999.9Hz |
| Display Type | Digital |
| Model Number p | Fluke 279 FC |
| AC Current Measurement Resolution | 1A ac |
| AC Voltage Measurement Resolution | 0.1mV ac |
| Resistance Measurement Resolution | 100m? |
| DC Voltage Measurement Resolution | 0.001V dc |
| Safety Category Level | CAT III, CAT IV |
| Temperature Measurement Resolution | 0.1°C |
| Capacitance Measurement Resolution | 1nF |
| Battery Type | Li-Ion |
| Best Resistance Measurement Accuracy | 1.5 % + 3 Digits |
| Maximum Operating Temperature | +50°C |
| Dimensions | 216 x 94 x 57mm |
| Best DC Voltage Accuracy | 0.15 % + 2 Digits |
| Best Temperature Measurement Accuracy | 5 °C |
| Best AC Voltage Accuracy | 1 % + 3 Digits |
| Best Capacitance Measurement Accuracy | 10 % |
| Best AC Current Accuracy | 3 % + 5 Digits |
| Width | 94mm |
| Length | 216mm |
| Minimum Operating Temperature | -10°C |
| Height | 57mm |
| Battery Life | 10 h |
| Weight | 800g |
| Safety Category Voltage | 600 V, 1000V |
