MILLIOHM METER MODEL 16502

    • SKU:
    • Brand: Chroma
    • Availability: Out Of Stock

    MILLIOHM METER MODEL 16502 |Buy Now Key Features ■ Basic accuracy : 0.05% ■ Pulsed test current output mode is used to reduce thermal EMFs affection on milliohm measurement ■ DC test current output mode is used to fasten measurement speed for inductive DUT ■ Dry-circuit test current output mode...



    Add to quote

    MILLIOHM METER MODEL 16502 |Buy Now

    Key Features

    ■ Basic accuracy : 0.05%

    ■ Pulsed test current output mode is used to reduce thermal EMFs affection on milliohm measurement

    ■ DC test current output mode is used to fasten measurement speed for inductive DUT

    ■ Dry-circuit test current output mode (limited Max. 20mV) is used to measure such contact resistances where the maximum open-circuit voltage must be limited to 50mV

    ■ Temperature correction (TC function) regardless of material or temperature

    ■ Useful temperature conversion function for motor/ coil evaluation

    ■ 4 channels R scan with balance check function for fan motor (combined with A165017 option)

    ■ 0.001mΩ~1.9999MΩ wide measurement range with 4½ digits resolution

    ■ Standard RS-232 interface

    ■ Optional GPIB & Handler interface

    ■ Bin-sorting function

    ■ Comparator and pass/fail alarming beeper function

    ■ Large LCD display (240 x 64 dot-matrix)

    ■ Friendly user interface

    ■ LabView® Driver
