weidmuller SCD 3.81/06/90G 3.2SN BK BX - 1973110000 OMNIMATE SC, 6 Way, 2 Row, Right Angle PCB Header
weidmuller SCD 3.81/06/90G 3.2SN BK BX - 1973110000 OMNIMATE SC, 6 Way, 2 Row, Right Angle PCB Header Product Description SCD Dual Row Headers - 90° 3.2mm Pin Length These Weidmuller SCD series of Double-level, 90°, Through Hole Headers have 3.2 mm solder pin lengths suitable for Wave soldering. Note...
weidmuller SCD 3.81/06/90G 3.2SN BK BX - 1973110000 OMNIMATE SC, 6 Way, 2 Row, Right Angle PCB Header
Product Description
SCD Dual Row Headers - 90° 3.2mm Pin Length
These Weidmuller SCD series of Double-level, 90°, Through Hole Headers have 3.2 mm solder pin lengths suitable for Wave soldering.
Note
For mating 3.81 mm pitch BCZ plug Socket Connectors see stock number for 180° and for 90° typical.
3.81mm Pitch - Weidmuller Omnimate Range
Specifications
Product Description
These Weidmuller SCD series of Double-level, 90°, Through Hole Headers have 3.2 mm solder pin lengths suitable for Wave soldering.
For mating 3.81 mm pitch BCZ plug Socket Connectors see stock number for 180° and for 90° typical.
3.81mm Pitch - Weidmuller Omnimate Range
Specifications
| Attribute | Value |
| Series | OMNIMATE SC |
| Pitch | 3.81mm |
| Number of Contacts | 6 |
| Number of Rows | 2 |
| Body Orientation | Right Angle |
| Shrouded/Unshrouded | Shrouded |
| Connector System | Wire to Board |
| Mounting Type | Through Hole |
| Termination Method | Solder |
| Contact Material | Copper Alloy |
| Current Rating | 17.5A |
