weidmuller BVZ 7.62HP/02/180 SN BK BX - 1929930000 BVZ 2-pin PCB Terminal Block, 7.62mm Pitch, Rows, Screw Termination
Product Description
Female plug in 180° outlet direction with clamping yoke screw connection for TNC (S) systems. The mating profile ensures touch-safety of > 3 mm. Maximum operational reliability: with a derating up to 125 °C, a mating profile that can only be plugged in correct, and unique coding capability.
Available with a flange (F), screw flange (SF) and clip on screw flange (SFC)
Specifications
Product Description
Female plug in 180° outlet direction with clamping yoke screw connection for TNC (S) systems. The mating profile ensures touch-safety of > 3 mm. Maximum operational reliability: with a derating up to 125 °C, a mating profile that can only be plugged in correct, and unique coding capability.
Available with a flange (F), screw flange (SF) and clip on screw flange (SFC)
Specifications
| Attribute | Value |
| Number of Contacts | 2 |
| Pitch | 7.62mm |
| Number of Rows | 1 |
| Mounting Type | Through Hole |
| Gender | Female |
| Termination Method | Screw |
| Type | PCB Terminal Block Header |
| Current Rating | 40A |
| Body Orientation | Right Angle |
| Colour | Black |
| Voltage Rating | 1 kV, 600 (CSA, UL 1059) V |
| Series | BVZ |
| Width | 41.2mm |
| Depth | 23.1mm |
| Material | Copper Alloy (Contact), PAGF (Insulation) |
| Length | 9.62mm |
