weidmuller 1024200000 Brown W Thermoelectric Voltage Terminal Block Pair, Single level, 2.5mm², 55 V
weidmuller 1024200000 Brown W Thermoelectric Voltage Terminal Block Pair, Single level, 2.5mm², 55 V Product Description W Series Modular Thermocouple Terminals A versatile and extensive range of 2.5 mm² thermocouple terminal blocks compatible with the most popular thermocouple types:8239726 - Type K8239720 - Type T8239739 - Type J8239732 - Type...
weidmuller 1024200000 Brown W Thermoelectric Voltage Terminal Block Pair, Single level, 2.5mm², 55 V
Product Description
W Series Modular Thermocouple Terminals
A versatile and extensive range of 2.5 mm² thermocouple terminal blocks compatible with the most popular thermocouple types:
8239726 - Type K
8239720 - Type T
8239739 - Type J
8239732 - Type SR
8239736 - Type B
8239745 - Type E
8239748 - Type N
Hardened steel for mechanical strength and high-quality tinned copper contacts for optimum conductivity. All materials comply with RoHS requirements and have been tested to current environment guidelines.
Features and Benefits
• Spring and screw connection technology
• Snap-on mounting
Approvals
CE, CSAEX, ATEX, EAC, Exi, IECEx-SIRA, IEC EC, INMETRO
The ’W’ series screw clamp terminals are suitable for ’Top Hat’ DIN Rail and manufactured from nylon 6.6 which has a continuous temperature rating of 120°C (180°C short term). They are self-extinguishing to UL94V-0 and free from cadmium and halogen. Current bars are constructed from 10 mm electrolytic copper to ensure a current loading more than nominal rating. Terminals are suitable for mounting on symmetric ’Top Hat’ rail only (BS5584:1978, EN 50022) and are touch proof in accordance with BS 3042.
Specifications
Product Description
A versatile and extensive range of 2.5 mm² thermocouple terminal blocks compatible with the most popular thermocouple types:
8239726 - Type K
8239720 - Type T
8239739 - Type J
8239732 - Type SR
8239736 - Type B
8239745 - Type E
8239748 - Type N
Hardened steel for mechanical strength and high-quality tinned copper contacts for optimum conductivity. All materials comply with RoHS requirements and have been tested to current environment guidelines.
8239726 - Type K
8239720 - Type T
8239739 - Type J
8239732 - Type SR
8239736 - Type B
8239745 - Type E
8239748 - Type N
Hardened steel for mechanical strength and high-quality tinned copper contacts for optimum conductivity. All materials comply with RoHS requirements and have been tested to current environment guidelines.
• Spring and screw connection technology
• Snap-on mounting
CE, CSAEX, ATEX, EAC, Exi, IECEx-SIRA, IEC EC, INMETRO
The ’W’ series screw clamp terminals are suitable for ’Top Hat’ DIN Rail and manufactured from nylon 6.6 which has a continuous temperature rating of 120°C (180°C short term). They are self-extinguishing to UL94V-0 and free from cadmium and halogen. Current bars are constructed from 10 mm electrolytic copper to ensure a current loading more than nominal rating. Terminals are suitable for mounting on symmetric ’Top Hat’ rail only (BS5584:1978, EN 50022) and are touch proof in accordance with BS 3042.
Specifications
| Attribute | Value |
| Colour | Brown |
| Number of Levels | Single |
| Series | W |
| American Wire Gauge | 26 ? 12AWG |
| Termination Method | Screw |
| Cable CSA | 2.5mm² |
| Voltage Rating | 55 V |
| Current Rating | 1 (ATEX)A |
| Pitch | 10.2mm |
| Minimum Operating Temperature | -50°C |
| Maximum Operating Temperature | +120°C |
