Allen-Bradley 1492-SPM1C100 MCB Supplementary Protector 10 A

  • DescriptionAllen Bradley 1492 SP Series Miniature Circuit Breakers – Type CExperience high performance and exceptional protection for electrical circuits with the general purpose 1492-SPM Type C Miniature Circuit Breakers by Allen Bradley.These 1492-SPM MCB’s have type C tripping and fast breaking time to provide a higher level of safety for...



    Add to quote

    Description

    Allen Bradley 1492 SP Series Miniature Circuit Breakers – Type C


    Experience high performance and exceptional protection for electrical circuits with the general purpose 1492-SPM Type C Miniature Circuit Breakers by Allen Bradley.

    These 1492-SPM MCB’s have type C tripping and fast breaking time to provide a higher level of safety for your application. They include screw terminals, are IP20 finger safe, and can be DIN rail mounted for optimal convenience. They are current-limiting and are available in 1, 2 or 3 pole versions, offering more versatility to meet your requirements. They also have dual terminals for wiring and bus bar flexibility. These units have excellent shock and vibration resistance which helps to prevent nuisance tripping, avoiding unnecessary downtime. Up to six accessories can be installed on the same circuit breaker to enable easy optimisation of your safety system.

    Type C MCB’s are suitable for use in commercial and light industrial applications, such as fluorescent lighting and small electric motors, and are designed to trip at currents between five and ten times their rated load.

    Features and Benefits:


    • Available in 1, 2 or 3 pole versions to suit your application needs
    • DIN Rail mountable in any position to ensure easy installation
    • Dependable protection for circuits due to instantaneous break time
    • Indicator window allows clear visibility of contact state: red for closed, green for open
    • Screw Terminals
    • Thermal-magnetic tripping mechanism
    • Can be used in extreme ambient conditions
    • RohS compliant and fully recyclable, offering a more environmentally friendly solution

    Certifications:


    UL Recognised
    CSA Certified
    CE Marked
    CCC Certified
    VDE Certified
    RoHS Compliant

    Standards:


    UL 1077
    CSA C22.2 No. 235
    EN 60947-2
    GB 14048.2

    Allen Bradley Miniature Circuit Breaker, Type C, 10A Current Rating- 1492-SPM1C100


    To prevent damage caused by short circuits, connect your electrical equipment to this miniature circuit breaker (MCB) from Rockwell Automation's Allen Bradley range. It has mechanical endurance of 20,000 operations, so you can count on it to last a long time without much maintenance. It has a type C curve, meaning it trips at five to ten times its 10A rated current. This makes it ideal for setups that have high-inductive loads with high switching surges. Installing the MCB into enclosed spaces is easy, thanks to its compact dimensions of 88 (height) x 74 (depth) x 17.5mm (width).

    Features & Benefits


    • Screw terminals ensure connections are electrically and physically secure
    • IP20 (ingress protection) rating indicates the unit is finger-safe and can be handled without risk of electric shocks
    • Simple mounting on a standard DIN rail

    Standards and Certifications


    • CE (Conformitè Europëenne)
    • VDE (Verband der Elektrotechnik)
    • UL (Underwriters' Laboratories)
    • CSA (Canadian Standards Association)

    How can I tell whether the switch has tripped or not?


    The switch on this miniature circuit breaker will be in the upward-facing position when on and facing down when the switch is tripped. For extra clarity, an additional indicator window shows a red bar when on and a green bar when off.


    Allen Bradley MCBs

    Specifications

    Attribute Value
    Number of Poles 1P
    Current Rating 10A
    Tripping Characteristics Type C
    Rated AC Voltage 277V
    Rated DC Voltage 48V
    Series 1492SPM
    Range 1492
    Breaking Capacity at Maximum Voltage Rating 10 kA
    Circuit Breaker Type MCB
    Mounting Style DIN Rail Mount
    Width 74mm
    Length 17.5mm
    Depth 88mm
    Terminal Contact Type Screw
    Reset Actuator Type Toggle Switch
    Break Time Instantaneous
    Tripping Mechanism Thermal-Magnetic
    Application General Purpose
