weidmuller 1863010000 OMNIMATE SC, 5 Way, 1 Row, Straight PCB Header
Product Description
SC-SMT Headers - 180° 3.2mm Pin Length
These Weidmuller SC-SMT series of 180°, Through Hole Shrouded Headers have 3.2 mm solder pin lengths suitable for either Through Hole Reflow (THR) soldering or Wave soldering.
Note
For mating 3.81 mm pitch BCZ plug Socket Connectors see stock number for 180° and for 90° typical.
3.81mm Pitch - Weidmuller Omnimate Range
Specifications
Product Description
These Weidmuller SC-SMT series of 180°, Through Hole Shrouded Headers have 3.2 mm solder pin lengths suitable for either Through Hole Reflow (THR) soldering or Wave soldering.
For mating 3.81 mm pitch BCZ plug Socket Connectors see stock number for 180° and for 90° typical.
3.81mm Pitch - Weidmuller Omnimate Range
Specifications
| Attribute | Value |
| Series | OMNIMATE SC |
| Pitch | 3.81mm |
| Number of Contacts | 5 |
| Number of Rows | 1 |
| Body Orientation | Straight |
| Shrouded/Unshrouded | Shrouded |
| Mounting Type | Through Hole |
| Connector System | Wire to Board |
| Termination Method | Solder |
| Contact Material | Copper Alloy |
| Current Rating | 17.5A |
