weidmuller 1864080000 OMNIMATE SC, 3 Way, 1 Row, Straight PCB Header
Product Description
SC-SMT Flanged Headers - 180° 1.5mm Pin Length
These Weidmuller SC-SMT series of 180°, Through Hole Flanged Headers have 1.5 mm solder pin lengths suitable for Through Hole Reflow (THR) soldering. The design of these SC-SMT LF series headers incorporates extra solder pins for increased strength between the PCB and header.
Note
For mating 3.81 mm pitch BCZ flanged plug Socket Connectors see stock number for 180° and for 90° typical.
3.81mm Pitch - Weidmuller Omnimate Range
Specifications
Product Description
These Weidmuller SC-SMT series of 180°, Through Hole Flanged Headers have 1.5 mm solder pin lengths suitable for Through Hole Reflow (THR) soldering. The design of these SC-SMT LF series headers incorporates extra solder pins for increased strength between the PCB and header.
For mating 3.81 mm pitch BCZ flanged plug Socket Connectors see stock number for 180° and for 90° typical.
3.81mm Pitch - Weidmuller Omnimate Range
Specifications
| Attribute | Value |
| Series | OMNIMATE SC |
| Pitch | 3.81mm |
| Number of Contacts | 3 |
| Number of Rows | 1 |
| Body Orientation | Straight |
| Shrouded/Unshrouded | Shrouded |
| Mounting Type | Through Hole |
| Connector System | Wire to Board |
| Termination Method | Solder |
| Contact Material | Copper Alloy |
| Current Rating | 17.5A |
