weidmuller 1123530000 DIN Rail Mount Interface Relay, 120V Coil, DPDT
weidmuller 1123530000 DIN Rail Mount Interface Relay, 120V Coil, DPDT Product Description Weidmuller TERMSERIES Relay Modules TERMSERIES complete relays modules consisting of a relay and base with AC/DC/UC coils, available in different versions: With screw and tension-clamp connectionAgNi contact, optionally with hard gold-plated contacts1 and 2 COsOptionally with multiple-voltage input:...
weidmuller 1123530000 DIN Rail Mount Interface Relay, 120V Coil, DPDT
Product Description
Weidmuller TERMSERIES Relay Modules
TERMSERIES complete relays modules consisting of a relay and base with AC/DC/UC coils, available in different versions:
With screw and tension-clamp connection
AgNi contact, optionally with hard gold-plated contacts
1 and 2 COs
Optionally with multiple-voltage input: 24...230 V UC
With various protective circuits in the input (free-wheel diode, RC element)
Illuminated ejection lever
Specifications
Product Description
TERMSERIES complete relays modules consisting of a relay and base with AC/DC/UC coils, available in different versions:
With screw and tension-clamp connection
AgNi contact, optionally with hard gold-plated contacts
1 and 2 COs
Optionally with multiple-voltage input: 24...230 V UC
With various protective circuits in the input (free-wheel diode, RC element)
Illuminated ejection lever
AgNi contact, optionally with hard gold-plated contacts
1 and 2 COs
Optionally with multiple-voltage input: 24...230 V UC
With various protective circuits in the input (free-wheel diode, RC element)
Illuminated ejection lever
Specifications
| Attribute | Value |
| Coil Voltage | 120V |
| Contact Configuration | DPDT |
| Mounting Type | DIN Rail |
| Switching Voltage | 250V ac |
| Terminal Type | Screw |
| Length | 90mm |
| Series | TRS |
| Depth | 12.8mm |
| Height | 88mm |
| Contact Material | Silver Alloy |
| Input Current | (dc) 3.5 mA, (ac) 3.5mA |
| Number of Poles | 2 |
| Input Voltage Range | 120V |
| Dimensions | 90 x 12.8 x 88mm |
| Maximum Operating Temperature | +60°C |
| Minimum Operating Temperature | -40°C |
| Turn Off Time | <7ms |
| Standards Met | CE, CULus, EAC, RoHS Compliant |
| Special Features | Illuminated Ejection Lever, Various Protective Circuits in the Input |
| Turn On Time | <11ms |
| Operating Temperature Range | -40 ? +60°C |
| Relay Switching Classification | General Purpose Relay |
