Allen-Bradley 872C-M12NP18-D4 Inductive Prox Sensor

SKU: 872C-M12NP18-D4
Brand: rockwell automations

Availability: In Stock

Allen-Bradley 872C-M12NP18-D4 Inductive Prox SensorPowerpro company Limited is the distributor, supplier and service provider of ( Test Equipment Product Sales, Test Equipment Calibration, Test Equipment Rentals and Product Training) in Nigeria.Description3-Wire DC Weld Field Immune3-wire operation4-pin micro quick-disconnectWeld field immunityWeld-slag resistant PTFE coated brass barrel and faceEqual sensing for all...

Allen-Bradley 872C-M12NP18-D4 Inductive Prox Sensor

Powerpro company Limited is the distributor, supplier and service provider of ( Test Equipment Product Sales, Test Equipment Calibration, Test Equipment Rentals and Product Training) in Nigeria.

Description

3-Wire DC Weld Field Immune

3-wire operation
4-pin micro quick-disconnect
Weld field immunity
Weld-slag resistant PTFE coated brass barrel and face
Equal sensing for all metals
Normally open output
Reverse polarity, short circuit, overload, false pulse and transient noise protection

Allen Bradley Inductive Proximity Sensor, Barrel Body Style, PNP Output - 872C-M12NP18-D4

Use this inductive proximity sensor from Rockwell Automation's Allen Bradley range in your machine for non-contact detection of objects within its vicinity. It's designed to detect objects within a 12mm range. This long sensing range allows for the sensor to be mounted further away from the target object, avoiding damage from impact. It's equipped with a PNP (positive negative positive) output that's easy for technicians to troubleshoot. This also serves to protect the sensor against hazardous situations like short-circuiting and overload.

Features and Benefits

• IP67 (ingress protection) rating certifying that this component is dust-tight and water-resistant
• Flush mounting style protects the face of the sensor from damage
• Chrome-plated brass housing for durability and corrosion resistance
• 4-pin micro quick disconnect makes replacing or moving the sensor easy and safe
• Maximum switching frequency of up to 500Hz, ensuring high-speed response times

Standards and Certifications

• BS EN 61340-5-1:2007 (Electrostatic Control Standards)
• ANSI/ESD S20.20:2014 (Electrostatic Control Standards)
• UL (Underwriters' Laboratories)
• CE (Conformité Européene)

What's the advantage of using this inductive proximity sensor?

This proximity sensor offers equal sensing ranges for all ferrous metals, eliminating the need to adjust to fit different target objects.

Specifications

Attribute	Value
Sensor Technology	Inductive
Body Style	Barrel
Thread Size	M18 x 1
Output Type	PNP
Detection Range	12 mm
Terminal Type	4-Pin M12 Connector
Supply Voltage	10 ? 30 V dc
IP Rating	IP67
Length	63.5mm
Maximum DC Voltage	30V
Mounting Type	Flush
Switching Current	200 mA
Maximum Operating Temperature	+70°C
Shielding	Shielded
Housing Material	Chrome Plated Brass
Maximum Switching Frequency	500Hz
Short Circuit Overload Protection	Yes
Reverse Polarity Protection	Yes
Minimum Operating Temperature	-25°C
